Wireless AP Router with VoIP



Feature Keys
• 4G-LTE
• 2.4GHz 300Mbps WiFi
• 10/100Mbps Ethernet
• Rich QoS capability in wired and wireless
Technical Parameters

Power
AC/DC Adapter
AC Input: 100~240V, 50~60Hz
DC Output: 12V, 1A
Operating System
Linux 2.6.36
I/O Interfaces
1 RJ-45 for WAN port (Ethernet 100 Base-T)
3 RJ-45 for LAN port (Ethernet 100 Base-T)
2 RJ-11 for FXS port
 SIM Card
IEEE802.11 b/g/n
Environmental
Operation Temperature: 0~50 Degree C
Storage Temperature: -25~ 85 Degree C
Relative Humidity: 10%~90% No Condensing
Audio Codec
G.711(A/u),PESQ>4.3
G.729AB,PESQ>3.7
 Adaptive Jitter Buffer Management
 Voice Activity Detection
 Comfort Noise Generation
 Echo Cancellation
 T.30 FAX with G.711
 Real time FAX over IP via T.38
LTE Features
Four-Band TDD-LTE B38/B39/B40/B41
Three-Band FDD-LTE B1/B3/B8
Dual-Band TD-SCDMA B34/B39
Dual-Band UMTS/HSDPA/HSPA+ B1/B8
GSM/GPRS/EDGE 900/1800 MHz
Uplink up to 50Mbps
Downlink up to 100Mbps
2G/3GFallback
Management
Firmware Upgrade
Web Management Interface
 IVR-driven Management Interface
Local and Remote Syslog (RFC3164)
Auto Provisioning
SNTP Time Synchronization
Multi User Level
SNMP v2
Telnet
TR069
Protocols
SIP V2.0 (RFC 3261)
Backward compatible with RFC2543
Session timer (RFC4028)
SDP (RFC2327)
RTP/RTCP (RFC1889/RFC1890)
NAPTR for SIP URI lookup (RFC2915)
STUN (RFC2030)
ARP/RARP (RFC 826/903)
SNTP (RFC 2030)
DHCP/PPPoE
HTTP Server for Web Management
TFTP/HTTP/HTTPS for Auto Provisioning
Message Waiting Indicator (RFC3842)
DHCP Option Codes for SIP (RFC3361)
DNS/DNS SRV (RFC1706 and RFC 2782)
TR069 (TR098,TR104)
IEEE802.1Q VLAN/802.1p/DSCP
 SNMP v2
Wireless
 802.11 b/g/n support
 4 SSID
 Static WEP(64/128bit)
 Dynamic WEP(64/128bit)
 AES(CCMP/TKIP)
 MAC certification
 WEP certification
 WPA-PAK/WPA-PSK(2.0)
 WPA/WPA2
 AP Isolation and MBSSID AP Isolation
 WMM
 WDS
 WPS
 Station list
 MAC Filter(different from wired MAC Filter)
Applications
 Support NAT mode and Bridge mode
 Support DDNS
 MAC address cloning
 SIP proxy redundancy
 NAT Traversal by STUN
 Built-in Wired speed NAT Router
 DHCP Server and Client
 IP conflict detection
 Port Forwarding, DMZ, SuperDMZ
 802.1Q VLAN/802.1p, DSCP, Rate Limiting
 VPN(PPTP,L2TP, OpenVPN) Passthrough,IPSec
 SNTP
 IGMPv2
 Firewall(DDoS attack)
Call Features
 3-way conference
 Call hold
 Call forwarding
 Call Transfer
 Call waiting
 Caller ID and CWCID
 DTMF Relay: In-band, Out-band and SIP INFO
 QoS Layer 3
 Call Log
 CID/CWCID
 Dial Plan
 DTMF Mode: Inband, RFC2833 and SIP Info
Regulatory
 FCC Part 15 Class B appoval
 CE certification
 RoHS compliance
SIZE And Weight
 158mm(L)x140mm(W)x29mm(H)
 225g(N.W)
