Product Description

The 26 Port Gigabit Web Managed Ethernet PoE Switch adopts high-quality and high-speed network IC. It has a

fan less and silent design, which completely solves the problem of high noise when small switches are deployed

in an office environment.This switch has 24* Gigabit POE RJ45 ports+ 2* Gigabit SFP ports, which can provide seamless connection for

10/100/1000M Ethernet, supports WEB management, and is easy to manage and maintain. This product can be widely used in security

network video surveillance, hotels, campuses, and small and medium-sized enterprises. Network engineering and other occasions.

Main Feature

Ø Support 24* Gigabit PoE RJ45 ports+2* Gigabit SFP Ports;

Ø Support IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z standard;

Ø Ethernet port supports 10/100/1000M adaptive;

Ø Support port auto flip(Auto MDI/MDIX);

Ø Adopting a storage and forwarding exchange mechanism;

Ø All ports support line speed switching;

Ø 1U rack installation;

Ø Panel indicator lights monitor working status and help failure analysis;

Ø Support QOS data priority;

Ø Surge Protection: General 4KV, Differential 2KV(level B), ESD 8KV air, 6KV contact (level C)

Specification

I/O Interface

Power

AC100-240V / 50-60Hz

Ethernet

24* 10/100/1000Mbps POE RJ45 Ports

2* Gigabit SFP Ports

Performance

Bandwidth

52Gbps

Pack Forward Rate

38.68Mpps

Pack Cache

4Mbit

VLAN

VLAN range 1-4094, with a maximum active VLAN of 31

MAC Address Table

8K

Jumbo Frame

9216Kbytes

Transfer Mode

Storage & Forward

Standard

Network Protocol



IEEE 802.3: Ethernet Media Access Control (MAC) Protocol

IEEE 802.3i: 10BASE-T Ethernet

IEEE 802.3u: 100BASE-TX Fast Ethernet

IEEE 802.3ab: 1000BASE-T Gigabit Ethernet

IEEE 802.3z: 1000BASE-X Gigabit Ethernet (fiber optic)

IEEE 802.3x: Flow Control

Industry Standard

EMS: EN61000-4-2 (ESD)

EN61000-4-5 (Surge)

Network Medium



10Base-T: Cat3, 4, 5 or above UTP/STP(≤100m)

100Base-TX: Cat5 or above UTP/STP(≤100m)

1000Base-TX: Cat5 or above UTP/STP(≤100m)

Fiber Optic Medium



Multi mode: 50/125, 62.5/125, 100/140um

Single mode: 8/125, 8.7/125, 9/125, 10/125um

Certification

Safety Certificate

CE, FCC, RoHS

Environment Standard

Working Environment



Working Temperature: -10~50°C

Storage Temperature: -40~70°C

Working Humidity: 10%~90%,non-condensing

Storage Temperature: 5%~95%,non-condensing

Function Indicator

Indicator

PWR(Power Indicator), 1000M(Link Light), Act(Link&Data Light)

PWR

On: Powered on

Off: Powered off

1000M

On: Gigabit link on

Off: 10/100M Link or Link off

Act

On: Link connecting

Flashing: Data transmitting

Off: Link off

Reset

Short press to restart long press 5S to restore factory settings

Physical Structure

Structure size



Product Size: 440*280*44mm

Package Size: 500*365*85mm

Product Net-Weight: 3.55KG

Product Gross-Weight: 4.22KG

Packing Info



Carton Size: 520*445*385mm

Packing Qty: 5 PCS

Packing Weight: 22.1KG

Power Voltage



Input Voltage: AC 100-240V 50/60Hz

Power Supply: 52V 7.69A

Consumption



Mother Board Power: Maximum 20W

POE Power: Maximum 380W

Packaging List

1 Switch, 1 Power cord, 1 Manual, 1 Certificate of Conformity, and 1 Pair of Hanging Ears

FUNCTION

L2 Function

Port

Port Switch Configuration

Port Speed Configuration

Port Duplex Configuration

Port Flow Control Configuration

Jumbo, Up to 9216bytes

EEE

Link Aggregation

Static Group

Up to 4 groups

Max. 8 members per group

Storm Control

Board cast

Unknown Multicast

Unknown Uni cast

Port Mirroring

support

Port Security

MAC Address Constraints

Port Isolation

support

Port Rate-limit

support

Loop back Detection

support

VLAN

Access/Trunk/Hybrid

VLAN range 1-4094, with a maximum active VLAN of 31

MAC Address

Dynamic Address

Static Address

Address Lookup

Spanning Tree Protocol

STP/RSTP

Edge Port

Multicast

IGMP Snooping

IGMP V1/V2

Router Port

Static IGMP Join

QOS

Traffic classification based, Strict priority and WRR

Port Priority

Supports up to 8 queues per port

Services

Access Protocol

HTTP

Port Statistics

support

Management

support

Manager IP

Static Address

DHCP Client

User

support

Firmware

Firmware Upgrade

Configuration

Upload and download

Save

support

Restart

support

Factory Defaults

support

Standards Compliance

IEEE 802.3x flow control and back pressure

IEEE 802.1D Spanning Tree Protocol

IEEE 802.1w Rapid Spanning Tree Protocol

IEEE 802.1p Class of Service

IEEE 802.1Q VLAN tagging

RFC 768 UDP

RFC 791 IP

RFC 792 ICMP

RFC 2068 HTTP

RFC 1112 IGMP v1

RFC 2236 IGMP v2
